Agriculture Gps Area Measurement Device Slope Measurement Tool

Name: Agriculture Gps Area Measurement Device Slope Measurement Tool
Brand: Wanggan
Price: 1 USD

Wholesale Agriculture Gps Area Measurement Device Slope Measurement Tool from china suppliers

Brand Name : Wanggan

Model Number : S3

Certification : ISO9001

Place of Origin : China

MOQ : 2 pieces

Payment Terms : Western Union, , T/T, MoneyGram

Supply Ability : 10000 pieces

Delivery Time : 8 working days

Packaging Details : 18*14*8cm.0.4kg

Product name : GPS Land Measuring Instrument Agriculture Vehicle Measuring Instrument Slope Measurement Tool

Function : GNSS GPS Land Survey Equipment

Color : Black+Blue

Weight : 120g(No battery)

Battery : Lithium Battery+AAA battery

Dimension : 117mm*61mm*20mm

Application : Handheld GPS Land Measuring Tools

Satellite signals : GPS GLONASS Galileo BeiDou

Working temperature : -20°C~65°C

Storage temperature : -40°C~75°C

Contact Now

GPS Land Measuring Instrument Agriculture Vehicle Measuring Instrument Slope Measurement Tool

Product Parameters:

Receiver chip	High sensitivity GNSS receiver chip
Receiver antenna	Passive large-size planar antenna
Efficient startup	1sec for warm boot, 30sec for cold boot.
Area accuracy	Measurement error within 0.03Mu(1-3Mu),2%(above 3Mu)
Distance accuracy	Within 1m(HDOP less than 1.0,measuring 100m in length)
Function characteristics	Longitude and latitude display,altitude display,area measurement,distance measurement,land price calculation
Data statistics	Area statistics,distance statistics
Area record	200pieces
Distance record	200pieces
Track display	The track will be displayed in real time in the course of measurement,it can also be viewed in statistical records.
Barometric leveling	About 1meter(Barometric measurement,the absolute altitude value needs to be calibrated)(just for S4) About 10meters(GPS measurement ,HDOP within 1.0)(just for S4 )
HDOP setting	Custom HDOP setting
Screen display	Color screen(320*240)
Prompt tone	Voice broadcast
Working temperature	-20℃～65℃
Storage temperature	-40℃～75℃
Equipment size	117mm×61mm×20mm
Equipment weight	120g(No battery)
Data interface	USB interface,it can be charged through this interface
Standard configuration	Host 1,lithium battery 1,charger 1,data line 1,lanyard 1,instruction 1,warranty card 1,packaging box 1.

•The unit price

①On the home page of boot,press the 【Settings】button to enter the settings interface；

②Press the▲▼button move to“unit setting”；Press the【Enter】button to enter；

③Press the【Enter】button to choose the unit price；

④Press ▲▼ button to adjust the value of number;

⑤After finishing setting,press the "Start" button to exit.

Note:After the setting of unit price, the amount can be viewed in the data display of the measurement interface, or in the measurement record details interface.
